21 Ton Excavator

21 Ton Excavator

Operating Weight
21 200kg

Bucket Capacity
0.9 - 1.2m³

The T-REX6210 has excellent fuel efficiency, reducing fuel consumption by 10%, which greatly reduces operating costs. New high-efficiency main pump is fully upgraded from previous models, with large displacement, which is 7% higher. A new generation instrument has an 8-inch large screen display, which can achieve faster data management and a more efficient control.

General Specs
SpecificationValue
Hydraulic Tank Volume246L
Operating Weight21 200kg
Engine ModelCummins 6BTAA5.9
Rated Power133kW @ 2 000 rpm
Bucket Capacity0.9 - 1.2m³
Bucket Digging Force138kN
Arm Digging Force99kN
Max. Traction174kN
Gradability35°
Max. Flow Rate223 * 2L/min
Working Pressure34.3 / 37.3MPa
Max. Digging Depth6 562mm
Max. Excavation Height9 275mm
Max. Unloading Height6 515mm
Max. Digging Distance9 865mm
Min. Turning Radius3 630mm
Overall Length9 390mm
Overall Width2 780mm
Track Shoe Width600mm
Fuel Tank Volume350L
Fuel Consumption14L/hr
Main PumpKawasaki K3V112DT
Main ValveCCHC VM30
Swing MotorCCHC MA170W
Travel MotorCCHC MA180T
